330 Stainless Steel Plate
330 stainless steel is a high-nickel chromium austenitic heat-resistant stainless steel, characterized by excellent oxidation resistance, carburization resistance, and resistance to thermal fatigue at extremely high temperatures (up to 1150°C), designed specifically for extreme environments such as high-temperature industrial furnaces.
Email：info@cnydpower.com
WhatsApp：+86 13820116383
Inquiry Now →

Product Introduction

330 Stainless Steel Plate is a high-performance nickel-chromium austenitic alloy specifically engineered for outstanding strength and resistance to oxidation, carburization, and thermal shock at extreme temperatures (up to 1150°C / 2100°F). Unlike standard stainless steels designed primarily for corrosion resistance, Alloy 330 (also known as RA 330®) is optimized for high-temperature mechanical integrity in harsh furnace atmospheres.

Its key characteristic is a balanced composition with significant silicon content (1.0-2.0%), which dramatically enhances its resistance to carburizing and oxidizing environments, as well as thermal cycling. This makes it the premier choice for critical furnace components, radiant tubes, heat treatment baskets, and other applications where 300-series stainless steels like 309/310 would rapidly degrade due to embrittlement or excessive scaling.

Product parameters


Item / ParameterSpecification for 330 / RA 330 (UNS N08330)Notes / Significance
Key FeatureSpecialized High-Temp Alloy. Superior resistance to oxidation, carburization, and thermal shock up to 1150°C.Designed for furnace hardware and thermal processing, not general corrosion resistance.
Common DesignationsUNS N08330, RA 330®, Alloy 330, AISI Type 330, EN 1.4886, JIS SUH330, W.Nr. 1.4886RA 330® is a registered trademark; UNS N08330 is the universal standard.
Chemical Composition (Typical wt.%)C: 0.05 - 0.10
Cr: 17.0 - 20.0Ni: 34.0 - 37.0 (Key: High Nickel)
Si: 1.0 - 2.0 (Key for oxidation/carburization resistance)
Mn: ≤ 2.00		High Ni provides austenitic stability and strength. High Si forms a protective SiO₂ layer under the Cr₂O₃ scale.
Mechanical Properties (Annealed Plate)Tensile Strength (Rm): ≥ 550 - 620 MPa
Yield Strength (Rp0.2): ≥ 240 - 280 MPa
Elongation (A): ≥ 30 - 40%
Hardness (HB): ≤ 201		Good room-temperature strength and ductility for fabrication.
High-Temperature PerformanceMax Continuous Service: 1150°C (2100°F) in oxidizing/carburizing atmospheres.
Key Strength: Resists carburization & nitriding; excellent thermal fatigue resistance.
Limitation: Avoid sulfur-bearing atmospheres at high temps.		The Si content is its "secret weapon" against carburization, a common failure mode for other alloys.
Key Standards (Plate)ASTM B536 (Standard Specification for UNS N08330 Plate, Sheet, and Strip)
AMS 5596 (Aerospace)		ASTM B536 is the primary material specification, not the typical A240 for stainless.
