403 Stainless Steel Coil
403 stainless steel coil is a type of martensitic stainless steel coil. The most crucial feature is its high strength and hardness. It is usually strengthened through heat treatment, but its corrosion resistance is relatively average.
Inquiry Now →

Product Introduction

403 Stainless Steel Coil is a martensitic stainless steel specifically formulated for high-temperature steam turbine applications, offering an optimal balance of strength, hardness, and corrosion resistance. With a controlled composition of 11.5-13.0% chromium and reduced silicon content compared to similar grades, 403 provides excellent resistance to scaling and oxidation at elevated temperatures while maintaining good mechanical properties and fabricability. Originally developed for steam turbine blades and other high-stress components in power generation equipment, this grade has become the standard for applications requiring reliable performance in demanding thermal environments.

Supplied in continuous coil form, 403 stainless steel combines the heat treatability and strength of martensitic stainless steels with improved high-temperature stability compared to standard 410 grade. Its carefully controlled chemistry minimizes delta ferrite formation, ensuring consistent mechanical properties and dimensional stability during heat treatment. While primarily associated with power generation, 403 has found applications across various industries where components must withstand combination of stress, temperature, and mildly corrosive environments, offering a cost-effective alternative to more highly alloyed materials.

Product parameters


Item / ParameterSpecification for 403 CoilNotes / Significance
Key FeatureThe Steam-Turbine Martensitic Stainless. Optimized chemistry for high-temperature strength, oxidation resistance, and reliable performance in steam and elevated temperature service.The traditional material choice for steam turbine blades and critical power generation components.
Common DesignationsUNS S40300
AISI 403
EN 1.4000, X6Cr13
JIS SUS403
AMS 5614 (Aerospace)
Often specified in aerospace and power generation standards for specific applications.
Chemical Composition (Typical wt.%)C: 0.08 - 0.15
Cr: 11.5 - 13.0
Mn: ≤ 1.00
Si: 0.15 - 0.35P: ≤ 0.040
S: ≤ 0.030
Lower silicon than 410 (0.15-0.35% vs ≤1.00%) improves high-temperature properties and reduces scaling.
Mechanical Properties (Annealed)Tensile Strength (Rm): ≥ 480 - 550 MPa
Yield Strength (Rp0.2): ≥ 275 - 345 MPa
Elongation (A): ≥ 20-25%
Hardness (HB): ≤ 201
Moderate properties in annealed condition; designed for enhancement through heat treatment.
Mechanical Properties (Hardened & Tempered)Tensile Strength: Up to 1300 MPa
Yield Strength: Up to 1100 MPa
Hardness: Up to 42 HRC
Elongation: 10-15%
Impact Toughness: Good
High strength achievable through proper heat treatment; suitable for dynamic loading.
Elevated Temperature PropertiesContinuous Service: Up to 700°C
Intermittent Service: Up to 750°C
Creep Strength: Good up to 600°C
Oxidation Resistance: Good up to 650°C
Specifically designed for steam turbine applications (typically 300-600°C).
Physical PropertiesDensity: 7.70 g/cm³
Melting Range: 1480 - 1530 °C
Thermal Expansion: 10.8 × 10⁻⁶/K (20-400°C)
Thermal Conductivity: 24.9 W/m·K (100°C)
Strongly magnetic
Lower thermal expansion than austenitic grades; beneficial for thermal cycling applications.
Heat Treatment CapabilityAustenitizing: 980-1010°C (air or oil quench)
Tempering Range: 550-650°C (for turbine applications)
Annealing: 815-870°C, slow cool
Stress Relief: 650-760°C
Typically tempered at higher temperatures than 410 for improved toughness.
Corrosion ResistanceModerate resistance to atmospheric corrosion, steam, and mild chemicals. Better than carbon steels but inferior to austenitic stainless steels.Suitable for steam, condensate, and mildly corrosive elevated temperature environments.
Key Standards (Coil)ASTM A240 (Plate, Sheet, and Strip)
ASTM A480 (General Requirements)
AMS 5614 (Aerospace)
ASTM A565 (for bars)
EN 10088-2
Often specified in specialized applications rather than general fabrication.
Common Applications (from Coil)• Steam Turbines: Blades, buckets, rotor components
• Power Generation: Valve parts, fasteners, structural components
• Aerospace: Compressor blades, engine components
• Industrial Equipment: Pump shafts, valve trim, wear plates
• Fasteners: High-temperature bolts, studs, nuts
• Tooling: Jigs, fixtures, molds for elevated temperature use
• Oil & Gas: Wellhead components, valve parts (non-corrosive services)
Specifically developed for and primarily used in steam turbine applications.
