Material Family

Nickel-Chromium-Iron-Aluminum Superalloy (Solid-Solution Strengthened)

Distinguished by its aluminum content, which enables superior high-temperature oxidation resistance.

Common Forms (Bar)

Hot Finished or Cold Finished Rounds, Hexagons, Squares. Also available as Forged Bar for large cross-sections or custom shapes.

Typically supplied in straight lengths. Hot finished bar is common for machining.

Chemical Composition (Typical wt.%)

Ni: 58.0-63.0 (Balance)
Cr: 21.0-25.0
Fe: ~14.2
Al: 1.0-1.7
C: ≤ 0.10

High Chromium & intentional Aluminum form a stable, protective alumina (Al₂O₃) scale at extreme temperatures.

Mechanical Properties (Annealed, Room Temp)

Tensile Strength (Rm): 655 - 895 MPa
Yield Strength (Rp0.2): 275 - 585 MPa
Elongation (A): 30 - 45%
Hardness: Typically 85-100 HRB

Offers higher typical strength than Inconel 600, especially at elevated temperatures.

Physical Properties

Density: 8.11 g/cm³
Melting Range: 1360 - 1410 °C
Max Continuous Service Temp: 1250°C (2282°F) in oxidizing atmospheres.

Optimized for maximum temperature capability and thermal cycling resistance.

Key Performance Attributes

• Outstanding Oxidation & Carburization Resistance in furnace atmospheres.
• Excellent Thermal Fatigue & Creep Rupture Strength for cyclic heating/cooling.
• Good resistance to sulfur-containing atmospheres and chloride environments at high temperatures.

The premier alloy bar for the most severe, high-temperature, oxidizing, and cyclic heating applications.

Key Standards (Bar)

ASTM B166 / ASME SB-166 (Grade UNS N06601), AMS 5713 (Aerospace Bar, Forging Stock)

Procured under the same ASTM standard as Inconel 600 bar, but to the N06601 composition.

Common Sizes & Conditions

Diameter/Thickness: 5mm (0.2") up to 250mm (10")+ diameter.
Condition: Annealed (Solution Annealed) or Hot Finished.

The Annealed condition is recommended for most machining operations to maximize tool life.

Machinability & Fabrication

Machinability Rating: Similar to Inconel 600 (~25%). Tough and work-hardening; requires rigid setups, positive rake tools, and adequate cooling.
Weldability: Good, using filler metals such as ENiCrFe-2 or ERNiCr-3.

Machining requires similar techniques to other solid-solution nickel superalloys: low speeds, high feeds, sharp tools.

Typical Bar Applications

• Industrial Furnaces: Radiant tube hangers, furnace rolls, retort brackets, thermocouple protection tubes, fan shafts.
• Heat Treatment: Fixture components, basket frames, conveyor pins, rollers.
• Power Generation: Combustion can components, burner nozzles, heat shield supports.
• Chemical Processing: Catalyst support grids, reactor internals for high-temperature processes.

The dominant bar material for high-temperature furnace and heat treatment fixture components requiring long-term stability.
